Aviation Connector Aerospace Connector J30T-21TJ Micro Rectangular Electrical Connector 21 pins Plug with high Temperature Conductor AFR,100cm Length J30T-21TJL-100cm
Aviation Connector Aerospace Connector J30T-21TJ Micro Rectangular Electrical Connector 21 pins Plug with high Temperature Conductor AFR,100cm Length J30T-21TJL-100cm
Overview
● Adopts twisted wire elastic pins (twisted pins), with high contact density and a spacing of 1.27mm.
● The product adopts a metal shielding shell, equivalent to the foreign M and MDM series.
● Including 11 common types such as 9-core to 100-core and 1 power type.
● The cross-sectional area of the wire core is 0.1mm2 ~0.15mm2.
● The product performance meets the requirements of GJB2446A and MIL-DTL-83513 standards
- sales@connector-sensor.com
- +86 15120067961
Scope of Application:
This product can be widely used for internal electrical signal connection of equipment and instrument cabins in industries such as aerospace, aviation, weapons, ships, communications, and computers.
Environmental Conditions
Working temperature: -55℃~125℃
Relative humidity: 90%~95% at 40±2℃
Atmospheric pressure: 101.3kpa~4.4kpa
Sinusoidal vibration: 10Hz~2000Hz, acceleration 196m/s2
Shock: 980m/s2
Acceleration: 980m/s2
Main Technical Performance
| Rated Current: | 3A, 13A (only 16# power type contact) |
| Contact Resistance: | ≤10mΩ |
| Insulation resistance: | ≥5000MΩ |
| Dielectric Withstand Voltage: | 800V |
| Mechanical Life: | 500 times |
| Air Leakage Rate Index (only for air-sealed products): | J30JM series: 5×10-2pa.cm3/s (rubber seal) J30JM1 series: 1×10-3pa.cm3/s (glass sintering) |
Dimensions：
Send Message to get Datasheet.
Strict Production Process
High purity silica (usually quartz or sand) and carbon (usually petroleum coke or coal) are ground to produce fine powder.
High purity silica (usually quartz or sand) and carbon (usually petroleum coke or coal) are ground to produce fine powder.
High purity silica (usually quartz or sand) and carbon (usually petroleum coke or coal) are ground to produce fine powder.
High purity silica (usually quartz or sand) and carbon (usually petroleum coke or coal) are ground to produce fine powder.
High purity silica (usually quartz or sand) and carbon (usually petroleum coke or coal) are ground to produce fine powder.
High purity silica (usually quartz or sand) and carbon (usually petroleum coke or coal) are ground to produce fine powder.
Strict Production Process of Yafeite
