Vortex Flow Meter – Reliable Steam, Gas & Liquid Flow Measurement for Industrial Applications
Product Description
The Vortex Flow Meter is a robust, high-precision digital flow measurement device designed for reliable monitoring of steam, gases, and liquids in industrial process applications. Based on the von Kármán vortex shedding principle, it detects flow velocity by measuring pressure pulses generated by alternating vortices behind a bluff body, ensuring stable and accurate readings without moving parts.
Unlike traditional turbine or differential pressure meters, this flow meter offers exceptional durability, low maintenance, and high turndown ratios (up to 30:1), making it ideal for variable flow conditions in power plants, chemical processing, and HVAC systems. Its advanced digital signal processing and temperature compensation deliver consistent performance across wide temperature and pressure ranges.
With multiple output options and compact design, the Vortex Flow Meter seamlessly integrates into existing SCADA/PLC systems, helping users reduce energy costs, improve process efficiency, and minimize downtime from mechanical wear.
Advantages of Vortex Flow Meter
- No moving parts design eliminates mechanical wear and maintenance
- Wide turndown ratio up to 30:1 for variable flow applications
- High accuracy ±1.0% with built-in temperature and pressure compensation
- Suitable for superheated steam, saturated steam, gases, and liquids
- Low pressure loss improves system energy efficiency
- Multiple output signals: 4–20 mA, Pulse, HART, Modbus RTU
- Robust construction withstands high temperatures up to 450°C
- Fast response time for real-time process monitoring
- Easy installation with flanged, wafer, or insertion mounting options
- ATEX/IECEx certified for hazardous area installations
Vortex Flow Meter Specifications
| Parameter | Specification |
|---|---|
| Measurement Principle | Von Kármán vortex shedding frequency |
| Fluid Type | Steam, compressed air, gases, liquids |
| Accuracy | ±1.0% of reading (liquids), ±1.5% (gas/steam) |
| Repeatability | ±0.3% |
| Turndown Ratio | 30:1 typical |
| Pipe Size Options | DN25–DN300 (1″ to 12″) |
| Process Temperature | –40°C to +450°C |
| Process Pressure | Up to 16 MPa (model dependent) |
| Frequency Range | 40 Hz to 6000 Hz |
| Output Signals | 4–20 mA, Pulse, RS485/Modbus, HART |
| Power Supply | 24V DC / 220V AC |
| Display | LCD with flow rate, totalizer, and diagnostics |
| Wetted Materials | 316L SS, Hastelloy (optional) |
| Explosion Proof | ATEX, IECEx, NEPSI certified |
| Ingress Protection | IP65/IP67 |
| Calibration | Factory calibrated with flow simulation |
Typical Applications of Vortex Flow Meter
Power Generation & Energy
Boiler feedwater and steam flow measurement
Condensate return line monitoring
Thermal energy consumption tracking
Chemical & Petrochemical Processing
Compressed air and inert gas flow control
Solvent and chemical feed lines
HVAC chilled/hot water systems
Oil & Gas Industry
Flare gas and vent gas measurement
Fuel gas metering for burners
Pipeline leak detection systems
Food & Pharmaceutical
Pure steam measurement for SIP/CIP
Process gas flow monitoring
Water treatment and utility monitoring
General Industrial
Compressed air leak detection and consumption
Nitrogen blanketing systems
Cooling tower water flow measurement
