Button Load Cell, Load Cell
Overview
Ultra-compact button design, diameter typically 10-30mm for tight spaces
Compression-only measurement, accuracy within ±0.25% to ±0.5% F.S
Capacity range from 5kg up to 100-200kg for precision force testing
Integral load button ensures optimum force application and alignment
Stainless steel construction, resists corrosion in industrial environments
Low deflection under 0.02mm at rated capacity for stable readings
IP53-IP65 protection against dust and moderate liquid exposure
Standard sensitivity 1.0-2.0 mV/V, compatible with basic instrumentation
Wide temperature range −20°C to +80°C with good thermal stability
Ideal for 3C testing, robotics, switches and micro-assembly applications
Digital Load Cell, Load Cell
Overview
- Built-in A/D conversion, RS485/RS232 or Modbus RTU digital output directly
- Plug-and-play digital communication, eliminates analog signal noise and interference
- High noise immunity, stable transmission up to 1km without repeaters
- Onboard calibration and temperature compensation for ±0.01% F.S. accuracy
- Multiple units daisy-chain connection, up to 32 cells on one bus
- Real-time force data output at 10-100Hz sampling frequency range
- Bus-powered operation, 5-24V DC input with low power consumption
- Remote configuration of zero, span, filter and threshold parameters
- Integrated overload protection and fault diagnostics via digital interface
- IP67 sealed housing, suitable for harsh industrial and outdoor environments
Miniature Force Sensor, Force Sensor
Overview
Ultra-compact 8-12mm diameter design
0.5-10kg capacity range available
±0.5% F.S. accuracy in miniature package
IP67 sealed stainless steel housing
1.0 mV/V output from 1000Ω bridge
Low deflection under 0.02mm at capacity
Temperature compensation -20°C to +80°C
300% safe overload protection
Lightweight 2-5g construction
Direct cable exit for tight installations
200 KG IP66 Planar Load Cell, Load Cell
Overview
200 KG compression capacity with planar design
±0.02% F.S. accuracy class performance
IP66 hermetic sealing for washdown protection
17-4PH stainless steel construction
Ultra-low profile height under 30mm
High resistance to side and eccentric loads
2.0 mV/V output from 400Ω input bridge
Temperature compensation -30°C to +70°C
150% safe overload with minimal deflection
4-bolt mounting pattern for easy installation
S Type Load Cell, Load Cell
Overview
S-shaped stainless steel structure measures bidirectional tension and compression forces
Capacity ranges from 1kg to 50 tons to suit various industrial applications
±0.02-0.05% F.S. accuracy class with nonlinearity and hysteresis below 0.02%
IP67/IP68 environmental sealing protects against dust, water, and corrosion
2.0 mV/V sensitivity from 350Ω strain gauge bridge for standard amplification
Temperature compensation maintains stability across -30°C to +70°C range
150-200% safe overload limit prevents damage from shock loading
Threaded mounting ends enable quick installation in cranes and hoppers
Low creep error under 0.02% ensures long-term measurement reliability
4/6-wire configuration simplifies integration with PLCs and data loggers
6 Axis Force Torque Sensor, Force Sensor
Overview
Captures forces (Fx, Fy, Fz) and torques (Mx, My, Mz) simultaneously for complete spatial load analysis
Supports forces from ±10N to ±2000N and torques up to ±50Nm, customizable for diverse applications
Nonlinearity and hysteresis typically ≤0.1-0.5% F.S. with low crosstalk <1-2.5% between axes
Often <0.05% F.S., enabling detection of subtle force variations in dynamic environments
Sampling rates up to 1kHz and response times <0.03-2 seconds for real-time control
Lightweight (200-1000g) with thin profiles (20-50mm height) using strain gauge or MEMS elastic bodies
200-500% safe overload capacity to withstand impacts without damage
IP65+ ratings, operating from -10°C to +85°C with long-term stability <0.5%/year
Analog voltage/current, digital CAN, RS485, EtherCAT, Ethernet, or I2C/SPI for easy robot/controller connectivity
Factory calibration, decoupling algorithms, and signal conditioning for plug-and-play use
Strong noise rejection for reliable operation in industrial or EMI-heavy settings
