2.92 MM Connectors
Features
- Clean, interference-free signal transmission from DC to 40 GHz — no higher-order modes
- Less than 0.5 dB insertion loss at 40 GHz keeps every measurement accurate and on spec
- Stable impedance matching maintained across the entire rated range, minimizing signal reflections
- Air dielectric construction eliminates dielectric loss and resists performance drift over temperature
- Mechanically compatible with SMA and 3.5mm connectors — no adapters, no extra hardware
- BeCu center contacts with gold plating deliver low contact resistance and lasting conductivity
- Passivated stainless steel housing rated for 500+ mating cycles in lab and field use
- Engineered to perform reliably from −65°C to +165°C across aerospace and defense environments
- Male, female, bulkhead, end launch, and adapters — one series covering every application
- Compliant with IEC 61169-35, MIL-PRF-39012, and MIL-STD-348. Full documentation available
2.4 MM Connectors
Features
- Extends usable bandwidth to 50 GHz, covering full Ka-band and advanced mmWave applications
- Consistent impedance matching maintained to 50 GHz, minimizing reflections throughout the signal chain
- Air-filled signal path eliminates dielectric absorption and keeps performance stable across temperatures
- Thicker outer conductor walls strengthen female socket fingers, resisting wear over repeated mating cycles
- Protective mating sequence shields the center contact from damage during every connection
- Mechanically mates with 1.85mm connectors, giving your system a clear upgrade path to 65 GHz
- Non-intermateable with SMA, 3.5mm, and 2.92mm connectors, preventing accidental damage to precision ports
- Beryllium copper contacts with gold plating deliver low contact resistance and long-term durability
- Manufactured to precision connector standards with full compliance documentation available per part number
APC3.5 Connectors
Features
Air boundary interface for high-frequency precision applications
Compact and lightweight design for space-sensitive installations
50 ohm characteristic impedance for standard RF systems
Frequency range from DC to 30GHz
VSWR of ≤1.05 + 0.01F for stable signal transmission
Operating temperature range from -55°C to +105°C
Insulation resistance ≥5000MΩ for reliable electrical isolation
Dielectric withstanding voltage of 750V
Low contact resistance, center conductor ≤0.003Ω and outer conductor ≤0.002Ω
Durability up to 500 mating cycles
Interchangeable with SMA series connectors
L29 Connectors
Features
Large screw-coupling structure for stable and secure connection
50 ohm impedance for standard RF system compatibility
DC to 7.5 GHz frequency range for broad RF and microwave use.2700V(rms) working voltage and 4000V(rms) withstanding voltage
Straight VSWR ≤1.25 and right-angle VSWR ≤1.40
Center contact resistance ≤0.001 Ω and outer contact resistance ≤0.0005 Ω
Insulation resistance ≥5000 MΩ for dependable electrical isolation
Operating temperature from -65°C to +155°C
Durability up to 500 mating cycles
Mostly waterproof construction for outdoor installation
BNC Connectors
Features
- Bayonet quarter-turn coupling locks securely in place, enabling fast connection and disconnection without tools
- Developed to MIL-C-39012/16-24 military specifications, ensuring proven performance in demanding RF environments
- Fully interchangeable with international same-series connectors, simplifying sourcing and system maintenance worldwide
- Compliant with Q/MB409-87 specifications, guaranteeing consistent dimensional accuracy across the entire product range
- Available in both 50Ω and 75Ω impedance versions, covering RF transmission and broadcast video applications respectively
- Comprehensive mounting styles — cable, bulkhead, flange, and PCB mount — support virtually every installation configuration
- Right angle versions redirect cable exit by 90 degrees, reducing strain and improving routing in compact enclosures
- Sealed BNC(S) and BNC(M) series incorporate O-ring protection, making them suitable for outdoor and harsh industrial environments
- Compatible with a wide range of coaxial cables, including SFF-50, SYV-50, SYV-75, SFT-50, and SDY-4 families
- Rated for 500 mating cycles, the robust brass body with nickel plating delivers long-term mechanical and electrical reliability
4-20MA Temperature and Humidity Sensors
Key Features
- Two independent 4-20mA channels transmit temperature and humidity simultaneously over one loop
- Measurement precision reaches ±0.5°C for temperature and ±2–3% RH for humidity
- Wide sensing range covers –40°C to +120°C and 0% to 100% RH for versatile deployment
- Excellent long-term stability keeps drift within ≤1% RH/year and ≤0.1°C/year
- Fast response delivers humidity readings within 8 s and temperature within 25 s
- Wide 10–30V DC supply voltage ensures flexible, hassle-free integration into any system
- IP40, IP65, and IP68 ratings cover indoor, outdoor, and harsh industrial environments
- Compact, wall-mountable housing installs easily into panels and electrical enclosures
- Optional LCD display enables clear on-site readings without additional instruments
- Optional RS485/Modbus RTU output adds digital communication alongside the analog loop
